Self-Flashing Roof Curb
CCP-SFRC
Standard Features
- 18ga. G90 min. construction
- 8" min. height (12" min. with damper tray)
- 2" x 2" Nominal wood nailer
- 1 1/2" rigid board (R6) insulation
- Continuous welded seams coated with corrosion inhibiting compound
- 3 1/2" base mounting flanges all 4 sides
- Note: Curb I.D. is approx. 3.5" less than the O.D.
Optional Features
- Damper Tray
- Heavy gauge galvanized steel
- .080 Aluminum construction
- 18ga. Stainless Steel, 304-2B construction
- Gasket material
- Interior metal liner (same type as exterior)
- Pressure Treated wood nailer
- Extended base flanges (specify size)
